Name: C-Band 5G Extreme Bandpass Filter
Brand: Norsat International Inc.
SKU: eBPF-CN-1
Price: 1000.00 USD
Availability: InStock

eBPF-CN-1

C-Band 5G Extreme Bandpass Filter

eBPF-C Series

$1,000.00

Quantity Available: 326

Next Availability: 0 Next Availability: 0 Next Availability: 0 Next Availability: 0 Next Availability: 0 Next Availability: Not Applicable Next Availability: 0 Next Availability: Not Applicable Next Availability: 0 Next Availability: 0 Next Availability: Not Applicable Next Availability: Not Applicable Next Availability: Not Applicable Next Availability: Not Applicable Next Availability: Not Applicable Next Availability: 0

Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks Next Availability Lead Time: 6 - 8 Weeks

Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada Ex Works: Richmond, BC, Canada

View Resellers Quantity

(Scroll to see specifications and documents)

View Family Datasheet

[{"id":42404234952887,"title":"1: 3.70 - 4.20 GHz \/ Made in China","option1":"1: 3.70 - 4.20 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-1","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 1: 3.70 - 4.20 GHz \/ Made in China","public_title":"1: 3.70 - 4.20 GHz \/ Made in China","options":["1: 3.70 - 4.20 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008567877815,"title":"1: 3.70 - 4.20 GHz \/ Made in Thailand","option1":"1: 3.70 - 4.20 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-1","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 1: 3.70 - 4.20 GHz \/ Made in Thailand","public_title":"1: 3.70 - 4.20 GHz \/ Made in Thailand","options":["1: 3.70 - 4.20 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"67877815","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42404234985655,"title":"2: 3.625 - 4.200 GHz \/ Made in China","option1":"2: 3.625 - 4.200 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 2: 3.625 - 4.200 GHz \/ Made in China","public_title":"2: 3.625 - 4.200 GHz \/ Made in China","options":["2: 3.625 - 4.200 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008567910583,"title":"2: 3.625 - 4.200 GHz \/ Made in Thailand","option1":"2: 3.625 - 4.200 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 2: 3.625 - 4.200 GHz \/ Made in Thailand","public_title":"2: 3.625 - 4.200 GHz \/ Made in Thailand","options":["2: 3.625 - 4.200 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"67910583","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42404235018423,"title":"3: 3.754 - 4.200 GHz \/ Made in China","option1":"3: 3.754 - 4.200 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-3","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 3: 3.754 - 4.200 GHz \/ Made in China","public_title":"3: 3.754 - 4.200 GHz \/ Made in China","options":["3: 3.754 - 4.200 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008567943351,"title":"3: 3.754 - 4.200 GHz \/ Made in Thailand","option1":"3: 3.754 - 4.200 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-3","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 3: 3.754 - 4.200 GHz \/ Made in Thailand","public_title":"3: 3.754 - 4.200 GHz \/ Made in Thailand","options":["3: 3.754 - 4.200 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"67943351","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42404235051191,"title":"4: 3.80 - 4.20 GHz \/ Made in China","option1":"4: 3.80 - 4.20 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 4: 3.80 - 4.20 GHz \/ Made in China","public_title":"4: 3.80 - 4.20 GHz \/ Made in China","options":["4: 3.80 - 4.20 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008567976119,"title":"4: 3.80 - 4.20 GHz \/ Made in Thailand","option1":"4: 3.80 - 4.20 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 4: 3.80 - 4.20 GHz \/ Made in Thailand","public_title":"4: 3.80 - 4.20 GHz \/ Made in Thailand","options":["4: 3.80 - 4.20 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"67976119","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42404235083959,"title":"5: 3.90 - 4.20 GHz \/ Made in China","option1":"5: 3.90 - 4.20 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-5","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 5: 3.90 - 4.20 GHz \/ Made in China","public_title":"5: 3.90 - 4.20 GHz \/ Made in China","options":["5: 3.90 - 4.20 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008568008887,"title":"5: 3.90 - 4.20 GHz \/ Made in Thailand","option1":"5: 3.90 - 4.20 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-5","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 5: 3.90 - 4.20 GHz \/ Made in Thailand","public_title":"5: 3.90 - 4.20 GHz \/ Made in Thailand","options":["5: 3.90 - 4.20 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"68008887","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42404235116727,"title":"6: 4.00 - 4.20 GHz \/ Made in China","option1":"6: 4.00 - 4.20 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-6","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 6: 4.00 - 4.20 GHz \/ Made in China","public_title":"6: 4.00 - 4.20 GHz \/ Made in China","options":["6: 4.00 - 4.20 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008568041655,"title":"6: 4.00 - 4.20 GHz \/ Made in Thailand","option1":"6: 4.00 - 4.20 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-6","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 6: 4.00 - 4.20 GHz \/ Made in Thailand","public_title":"6: 4.00 - 4.20 GHz \/ Made in Thailand","options":["6: 4.00 - 4.20 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"68041655","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42404235149495,"title":"7: 4.10 - 4.20 GHz \/ Made in China","option1":"7: 4.10 - 4.20 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-7","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 7: 4.10 - 4.20 GHz \/ Made in China","public_title":"7: 4.10 - 4.20 GHz \/ Made in China","options":["7: 4.10 - 4.20 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008568074423,"title":"7: 4.10 - 4.20 GHz \/ Made in Thailand","option1":"7: 4.10 - 4.20 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-7","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 7: 4.10 - 4.20 GHz \/ Made in Thailand","public_title":"7: 4.10 - 4.20 GHz \/ Made in Thailand","options":["7: 4.10 - 4.20 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"68074423","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42404235182263,"title":"8: 3.820 - 4.200 GHz \/ Made in China","option1":"8: 3.820 - 4.200 GHz","option2":"Made in China","option3":null,"sku":"eBPF-CN-8","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 8: 3.820 - 4.200 GHz \/ Made in China","public_title":"8: 3.820 - 4.200 GHz \/ Made in China","options":["8: 3.820 - 4.200 GHz","Made in China"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41008568107191,"title":"8: 3.820 - 4.200 GHz \/ Made in Thailand","option1":"8: 3.820 - 4.200 GHz","option2":"Made in Thailand","option3":null,"sku":"eBPF-C-8","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"C-Band 5G Extreme Bandpass Filter - 8: 3.820 - 4.200 GHz \/ Made in Thailand","public_title":"8: 3.820 - 4.200 GHz \/ Made in Thailand","options":["8: 3.820 - 4.200 GHz","Made in Thailand"],"price":100000,"weight":1300,"compare_at_price":null,"inventory_management":"shopify","barcode":"68107191","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Norsat’s C-band interference extreme band pass filter features a broad passband with low insertion loss, steep skirts that roll off quickly and high stopband rejection. eBPF-C Series.

KEY SPECIFICATIONS
band	C-Band
input frequency band 1	3.70 - 4.20 GHz
number of onboard LOs	Single-Band
Product Revision	B

RF SPECIFICATIONS
output VSWR	1.9 : 1 max.

INTERFACE SPECIFICATIONS
RF input connector	CPR 229G waveguide grooved

PHYSICAL SPECIFICATIONS
product dimensions (LxWxH)	185 x 100 x 71 mm
product weight	0.97 kg

RF SPECIFICATIONS
input VSWR	1.4 : 1 max.
insertion loss in band	1.4 dB max.
output VSWR	1.9 : 1 max.

RF SPECIFICATIONS
input VSWR	1.4 : 1 max.
insertion loss in band	1.4 dB max.
output VSWR	1.9 : 1 max.

RF SPECIFICATIONS
input VSWR	1.4 : 1 max.
insertion loss in band	1.4 dB max.
output VSWR	1.9 : 1 max.

RF SPECIFICATIONS
input VSWR	1.4 : 1 max.
insertion loss in band	1.4 dB max.
output VSWR	1.9 : 1 max.

RF SPECIFICATIONS
input VSWR	1.4 : 1 max.
insertion loss in band	1.4 dB max.
output VSWR	1.9 : 1 max.

KEY SPECIFICATIONS
band	C-Band
group delay variation within 0.5MHz	3.0 ns max.
input frequency band 1	3.70 - 4.20 GHz
number of onboard LOs	Single-Band
rejection	60 dB min at 3.682 GHz; 25 dB min at 4.230 GHz
Product Revision	B

INTERFACE SPECIFICATIONS
RF input connector	CPR 229G waveguide grooved
RF output connector	CPR-229F

PHYSICAL SPECIFICATIONS
product dimensions (LxWxH)	170 x 100 x 71 mm
product weight	0.9 kg

PHYSICAL SPECIFICATIONS
product dimensions (LxWxH)	160 x 100 x 71 mm
product weight	0.9 kg

INFORMATION
HS Code	8517690000
Country of Origin	Made in Thailand
Ex Works	Richmond, BC, Canada
ECCN Number	EAR99
Unit Package Dimensions	270 x 140 x 115 mm
Unit Package Weight	1.3 kg
COMPLIANCE
	Yes
	Yes
